Hayatın Olduğu Her Yerde
Standby (kVA)
Motor
| STANDBY | PRIME | SÜREKLI ÇIKIŞ AKIMI | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Model | KVA | KW | KVA | KW | AMPER | Motor | |||
|
FP-10 | 10 | 8 | 9.1 | 7.2 | 13.1 | PERKINS | ||
|
FN-12 | 12 | 9.6 | 10.9 | 8.7 | 15.7 | YANGDONG | ||
|
FN-17 | 17 | 13.6 | 15.4 | 12.3 | 22.2 | YANGDONG | ||
|
FP-17 | 17 | 13.6 | 15.4 | 12.3 | 22.1 | PERKINS | ||
|
FB-20 | 20 | 16 | 18 | 14 | 25.9 | BAUDOUIN | ||
|
FN-22 | 22 | 17.6 | 20 | 16 | 28.8 | YANGDONG | ||
|
FP-22 | 22 | 17.6 | 20 | 16 | 28.8 | PERKINS | ||
|
FB-25 | 25 | 20 | 22.5 | 18 | 32.4 | BAUDOUIN | ||
|
FN-28 | 28 | 22.4 | 25.4 | 20.3 | 36.5 | YANGDONG | ||
|
FC-30 | 30 | 24 | 27.2 | 21.8 | 39.2 | CUMMINS | ||
|
FN-33 | 33 | 26.3 | 30 | 24 | 43.2 | YANGDONG | ||
|
FP-33 | 33 | 26.4 | 30 | 24 | 43.2 | PERKINS | ||
|
|
FB-35 | 35 | 28 | 31.8 | 25 | 45 | BAUDOUIN | ||
|
FK-35 | 35 | 28 | 31.8 | 25.4 | 45.8 | KOFO | ||
|
FR-35 | 35 | 28 | 31.8 | 25.4 | 45.8 | FULL | ||
|
FN-40 | 40 | 32 | 36.3 | 29 | 52.2 | YANGDONG | ||
|
FB-44 | 44 | 35 | 40 | 32 | 57.6 | BAUDOUIN | ||
|
FC-44 | 44 | 35.2 | 40 | 32 | 57.6 | CUMMINS | ||
|
FK-44 | 44 | 35.2 | 40 | 32 | 57.6 | KOFO | ||
|
FR-44 | 44 | 35.2 | 40 | 32 | 57.6 | FULL | ||
|
FB-50 | 50 | 40 | 45 | 36 | 64.8 | BAUDOUIN | ||
|
FK-50 | 50 | 40 | 45.5 | 36.4 | 65.5 | KOFO | ||
|
FN-50 | 50 | 40 | 45.4 | 36.3 | 65.3 | YANGDONG | ||
|
FP-50 | 50 | 40 | 45 | 36 | 65 | PERKINS | ||
|
FR-50 | 50 | 40 | 45.5 | 36.4 | 65.5 | FULL | ||
|
FB-55 | 55 | 44 | 50 | 40 | 72 | BAUDOUIN | ||
|
FR-60 | 60 | 48 | 54.5 | 43.6 | 78.5 | FULL | ||
|
FC-63 | 63 | 50.4 | 57.2 | 45.8 | 82.3 | CUMMINS | ||
|
FK-66 | 66 | 52.8 | 60 | 48 | 86.4 | KOFO | ||
|
FN-66 | 66 | 52.8 | 60 | 48 | 86.4 | YANGDONG | ||
|
FP-66 | 66 | 52.8 | 60 | 48 | 86.4 | PERKINS | ||
|
FB-72 | 72 | 57 | 65 | 52 | 93.6 | BAUDOUIN | ||
|
FP-72 | 72 | 57.6 | 65.4 | 52.3 | 94 | PERKINS | ||
|
FN-77 | 77 | 61.6 | 70 | 56 | 100.8 | YANGDONG | ||
|
FR-77 | 77 | 61.6 | 70 | 56 | 100.8 | FULL | ||
|
FK-80 | 80 | 64 | 72.7 | 58.2 | 104.7 | KOFO | ||
|
FB-88 | 88 | 70 | 80 | 64 | 115 | BAUDOUIN | ||
|
FC-88 | 88 | 70.4 | 80 | 64 | 115 | CUMMINS | ||
|
FP-88 | 88 | 70.4 | 80 | 64 | 115.2 | PERKINS | ||
|
FN-94 | 94 | 75.2 | 85.5 | 68.4 | 123 | YANGDONG | ||
|
FR-94 | 94 | 75.2 | 85.4 | 68.3 | 122.9 | FULL | ||
|
|
FB-110 | 110 | 88 | 100 | 80 | 93.6 | BAUDOUIN | ||
|
FC-110 | 110 | 88 | 100 | 80 | 144 | CUMMINS | ||
|
FK-110 | 110 | 88 | 100 | 80 | 144 | KOFO | ||
|
FN-110 | 110 | 88 | 100 | 80 | 144 | YANGDONG | ||
|
FP-110 | 110 | 88 | 100 | 80 | 144 | PERKINS | ||
|
FR-110 | 110 | 88 | 100 | 80 | 144 | FULL | ||
|
FR-125 | 125 | 100 | 113 | 90 | 163 | FULL | ||
|
FB-150 | 150 | 120 | 136 | 109 | 216 | BAUDOUIN | ||
|
FC-150 | 150 | 120 | 136 | 109 | 196 | CUMMINS | ||
|
FK-150 | 150 | 120 | 136 | 108 | 196 | KOFO | ||
|
FN-150 | 150 | 120 | 136 | 108 | 196 | YANGDONG | ||
|
FP-150 | 150 | 120 | 136 | 110 | 195 | PERKINS | ||
|
FR-150 | 150 | 120 | 136 | 108 | 196 | FULL | ||
|
|
FB-165 | 165 | 132 | 150 | 120 | 216 | BAUDOUIN | ||
|
FP-165 | 165 | 132 | 150 | 120 | 216 | PERKINS | ||
|
FC-175 | 175 | 140 | 159 | 127 | 229 | CUMMINS | ||
|
FK-175 | 175 | 140 | 160 | 128 | 230.4 | KOFO | ||
|
FR-175 | 175 | 140 | 160 | 128 | 230.4 | FULL | ||
|
FC-200 | 200 | 160 | 182 | 146 | 262 | CUMMINS | ||
|
FK-200 | 200 | 160 | 182 | 145 | 262 | KOFO | ||
|
FN-200 | 200 | 160 | 181 | 145 | 260 | YANGDONG | ||
|
FP-200 | 200 | 160 | 182 | 145 | 262 | PERKINS | ||
|
FB-220 | 220 | 176 | 200 | 160 | 288 | BAUDOUIN | ||
|
FC-220 | 220 | 176 | 200 | 160 | 288 | CUMMINS | ||
|
FG-220 | 220 | 176 | 200 | 160 | 288 | SD | ||
|
FP-220 | 220 | 176 | 200 | 160 | 288 | PERKINS | ||
|
FB-250 | 250 | 200 | 227 | 181 | 326 | BAUDOUIN | ||
|
FC-250 | 250 | 200 | 227 | 182 | 327 | CUMMINS | ||
|
FG-250 | 250 | 200 | 227 | 182 | 327 | SD | ||
|
FP-250 | 250 | 200 | 227 | 182 | 327 | PERKINS | ||
|
FB-275 | 275 | 220 | 250 | 200 | 360 | BAUDOUIN | ||
|
FC-275 | 275 | 220 | 250 | 200 | 360 | CUMMINS | ||
|
FP-275 | 275 | 220 | 250 | 200 | 360 | PERKINS | ||
|
FB-300 | 300 | 240 | 273 | 218 | 393 | BAUDOUIN | ||
|
FC-325 | 325 | 260 | 295 | 237 | 425 | CUMMINS | ||
|
FG-330 | 330 | 264 | 300 | 240 | 432 | SD | ||
|
FP-330 | 330 | 264 | 300 | 240 | 432 | PERKINS | ||
|
FB-350 | 350 | 280 | 318 | 254 | 457 | BAUDOUIN | ||
|
FC-350 | 350 | 280 | 318 | 255 | 458 | CUMMINS | ||
|
FC-385 | 385 | 308 | 350 | 280 | 505 | CUMMINS | ||
|
FG-385 | 385 | 308 | 350 | 280 | 504 | SD | ||
|
FB-400 | 400 | 320 | 364 | 290 | 524 | BAUDOUIN | ||
|
FP-400 | 400 | 320 | 364 | 290 | 524 | PERKINS | ||
|
FC-420 | 420 | 336 | 382 | 306 | 550 | CUMMINS | ||
|
FB-450 | 450 | 360 | 410 | 327 | 590 | BAUDOUIN | ||
|
FC-450 | 450 | 360 | 409 | 327 | 588 | CUMMINS | ||
|
FG-450 | 450 | 360 | 409 | 327 | 588 | SD | ||
|
FP-450 | 450 | 360 | 410 | 327 | 590 | PERKINS | ||
|
FB-500 | 500 | 400 | 454 | 363 | 653 | BAUDOUIN | ||
|
FC-500 | 500 | 400 | 454 | 363 | 653 | CUMMINS | ||
|
FG-495 | 500 | 400 | 454 | 363 | 653 | SD | ||
|
FP-500 | 500 | 400 | 454 | 363 | 653 | PERKINS | ||
|
|
FB-550 | 550 | 440 | 500 | 400 | 720 | BAUDOUIN | ||
|
FC-550 | 550 | 440 | 500 | 400 | 720 | CUMMINS | ||
|
FG-550 | 550 | 440 | 500 | 400 | 720 | SD | ||
|
FP-550 | 550 | 440 | 500 | 400 | 720 | PERKINS | ||
|
FC-570 | 570 | 456 | 518 | 414 | 746 | CUMMINS | ||
|
FG-600 | 600 | 480 | 545 | 436 | 784 | SD | ||
|
FB-660 | 660 | 528 | 600 | 480 | 864 | BAUDOUIN | ||
|
FG-660 | 660 | 528 | 600 | 480 | 864 | SD | ||
|
FP-660 | 660 | 528 | 600 | 480 | 864 | PERKINS | ||
|
FC-690 | 690 | 552 | 630 | 505 | 910 | CUMMINS | ||
|
FB-725 | 725 | 580 | 659 | 527 | 949 | BAUDOUIN | ||
|
FG-725 | 725 | 580 | 659 | 527 | 948 | SD | ||
|
FP-725 | 725 | 580 | 660 | 528 | 950 | PERKINS | ||
|
FB-750 | 750 | 600 | 681 | 544 | 980 | BAUDOUIN | ||
|
FC-750 | 750 | 600 | 681 | 545 | 980 | CUMMINS | ||
|
FP-780 | 780 | 624 | 709 | 567 | 1020 | PERKINS | ||
|
FG-790 | 790 | 632 | 718 | 574 | 1033 | SD | ||
|
FB-825 | 825 | 660 | 750 | 600 | 1080 | BAUDOUIN | ||
|
FC-825 | 825 | 660 | 750 | 600 | 1080 | CUMMINS | ||
|
FG-840 | 840 | 672 | 763 | 610 | 1098 | SD | ||
|
FP-850 | 850 | 680 | 772 | 618 | 1110 | PERKINS | ||
|
FB-900 | 900 | 720 | 818 | 655 | 1178 | BAUDOUIN | ||
|
FC-900 | 900 | 720 | 818 | 654 | 1177 | CUMMINS | ||
|
FP-900 | 900 | 720 | 818 | 655 | 1178 | PERKINS | ||
|
FG-925 | 925 | 740 | 840 | 672 | 1210 | SD | ||
|
|
FB-1000 | 1000 | 800 | 910 | 728 | 1178 | BAUDOUIN | ||
|
FC-1000 | 1000 | 800 | 909 | 727 | 1308 | CUMMINS | ||
|
FG-1000 | 1000 | 800 | 909 | 727 | 1300 | SD | ||
|
FP-1000 | 1000 | 800 | 910 | 728 | 1310 | PERKINS | ||
|
FC-1100 | 1100 | 880 | 1000 | 800 | 1440 | CUMMINS | ||
|
FB-1125 | 1125 | 900 | 1022 | 817 | 1470 | BAUDOUIN | ||
|
FP-1125 | 1125 | 900 | 1022 | 817 | 1470 | PERKINS | ||
|
FB-1250 | 1250 | 1000 | 1136 | 908 | 1635 | BAUDOUIN | ||
|
FC-1250 | 1250 | 1000 | 1136 | 908 | 1635 | CUMMINS | ||
|
FG-1125 | 1250 | 1000 | 1136 | 908 | 1636 | SD | ||
|
FP-1250 | 1250 | 1000 | 1136 | 908 | 1635 | PERKINS | ||
|
FP-1385 | 1385 | 1108 | 1259 | 1007 | 1813 | PERKINS | ||
|
FB-1400 | 1400 | 1120 | 1272 | 1018 | 1832 | BAUDOUIN | ||
|
FC-1400 | 1400 | 1120 | 1272 | 1080 | 1832 | CUMMINS | ||
|
FB-1500 | 1500 | 1200 | 1363 | 1090 | 1963 | BAUDOUIN | ||
|
FB-1650 | 1650 | 1320 | 1600 | 1200 | 2160 | BAUDOUIN | ||
|
FC-1650 | 1650 | 1320 | 1500 | 1200 | 2160 | CUMMINS | ||
|
FP-1650 | 1650 | 1320 | 1500 | 1200 | 2160 | PERKINS | ||
